- High-concerned chemical: None
- Communication method: Zigbee
- Camera Equipped: No
- State of Assembly: Ready-to-Go
- Model Number: Zigbee DIY breaker relay
- Compatibility: All Compatible
- Brand Name: GIRIER
- Origin: Mainland China
- Certification: CE,RoHS
• ZigBee 3.0 technology :The switch module uses ZigBee 3.0 technology, which provides a stable and reliable connection for your smart home devices.
• 10A capacity :With a capacity of 10A, this switch module can handle high-power devices like air conditioners and heaters without any issues.
• 2-way control :The switch module supports 2-way control, allowing you to control your devices from both the switch and your smartphone.
• Alexa and Google Home compatibility :The switch module is compatible with Alexa and Google Home, allowing you to control your devices with voice commands.
Why Choose This ZigBee Switch Module?
-Support physical 2-way control.
-Possess the ability to power-fail memory function.
-Convenient remote control function via Smart Life/TuyaSmart app.
-Hands free voice control via Alexa/Google Home.
-Countdown/schedule/loop/random and inching timer you can set in app.
-ZigBee version that is more stable and safer.
-Tuya ZigBee Hub is required for pairing and app control.
—(The specification and the note are shown at the bottom)
App Remote Control
Remote control lighting or home appliances via Smart Life app from anywhere at anytime.
Voice Control
The ZigBee DIY switch works with Alexa and Google Home Assistant to conveniently control the appliances with simple voice command when you are on go.
Schedule Timer
Create schedules to automatically turn the home appliances or lighting on/off. Helping you saving energy and electric fee.
Relay Status Setting
Never worry about power failure, you can set this switch to restore the state after power on.
Tuya ZigBee Hub Required
A Tuya ZigBee hub is a must to the ZigBee smart switch for app remote control and voice control. Also, you can link other Tuya ZigBee products with the hub to realize a complete smart home system for your house.
Wiring diagrams
Small and Compact
Tiny body suitable for various of mounting boxes.
Sharing Function
Sharing the ZigBee switch module with family members by Smart Life app to control together.
INSTRUCTION MANUAL
–NOTICE
1.Tuya ZigBee Hub is required for pairing and app control.
2.Neutral wire is required.
3.This switch module doesn’t support dimmable bulb,smart bulb and light strips.
4.Only support 2.4GHz network.
SPECIFICATION
Shell Material: PC/Flammability
Rating: V0
Rated Voltage: 100~240V 50/60Hz
Rated Current: 10A
Size: 39.2*39.2*18mm
ZigBee Standard: IEEE 802.15.4
Geoperazzjoni Humidity: <90%
Operation Temperature: -10~40℃
App: TuyaSmart/Smart Life
Voice Control: Alexa/Hey Google
FAQ
1. Can it work with Alice?
A:Yes , it works with Yandex Alice.
2. Can it record the power consumption reports of home appliances?
A:No, it has no power monitor function.
3. Does this module need a gateway?
A:Yes, it is Tuya ZigBee hub required.
4. Can I control it when I am on vacation or on business?
A:Yes, you can control it by app anywhere and anytime, pls don’t worry.
5. Does this smart switch have power failure memory function?
A:Yes, it has.
6.Is it compatible with touch switch?
A: No. It is compatible with mechanical reset switch or rocker switch. You can choose suitable switch type in app.
7.Can it work as a ZigBee repeater?
A:Yes. It can work as a ZigBee repeater.
